Ubuntu Mate 20.04 Argon One Fan Control ( and Ubuntu Mate 22.04 )
Due to an issue with a kernel flag not being set the in the Ubuntu Kernal the current Argon One fan control script has an issue, the control system attempts to access /dev/mem to setup the shutdown button, this call fails with a segmentation fault. The recommendation was to add the current user to the "gpio" group or run this as sudo, however it does not work and fails to start due to the segmentation fault.
Even basic GPIO functions with Ubuntu 20.04 are now not possible, we did attempt to use GPIOZero and this library also has issues when communicating with the GPIO in the exact same way rpi.GPIO does. This is down to a simple fact that you cannot use the older GPIO libraries with Ubuntu 20.04, there is a new version called python3.lgpio but this only functions on Ubuntu 21.04 which has an updated version of Python to version 3.9. Even updating Python to 3.9 on Ubuntu 20.04 does not permit us to install the new library.
The Argon One case requires a one-line script to be run on the Raspberry Pi using the case's fan function correctly this script has been patched to address this issue.
It works with raspbian however the reason for the segfault is that the Ubuntu kernel is now built with CONFIG_STRICT_DEVMEM set true. It is unset in the raspbian kernel. (It is a setting under Kernel Hacking) you can only enable this by a kernal recompile which is not ideal. We have verified that the latest kernel does in fact have CONFIG_STRICT_DEVMEM=true.
The Argon One case is a solid Aluminum alloy case for the Raspberry Pi 4 that offers both passive and active cooling (see https://www.argon40.com/argon-one-raspberry-pi-4-case.html).
This script has been adapted from the original installation script which was designed to work with Raspbian (Raspberry OS); the modified scripted has been developed for use with Ubuntu 20.04 and Ubuntu Mate 20.04.
The modified script contains three changes to the original script:
- Switch to python3 since python2 support for GPIO has been nuked in Ubuntu 20.04.
- Reading the temperature cannot be done using
vcgencmd, so use
- Package dependencies have been adapted for Ubuntu & Ubuntu Mate 20.04.
Feel free to review the source code of the modified script before installation.
cd /tmp/ wget https://www.digiqrp.com/storage/downloads/argon1/argon1.sh chmod a+x argon1.sh sudo ./argon1.sh
When the script has completed run "sudo systemctrl start argononed" and then "sudo systemctrl status argononed", there is no need to re-boot.
Upon installation of the Argon One Pi 4 script for Ubuntu 20.04, the setting of the Argon one Pi 4 cooling system are as follows:
|CPU Temp||Fan Power|
However, you may change or configure the Fan to your desired settings by using
argonone-config to configure the fan behavior.
You can also from this utility set as may temperature steps that you wish with option 3, you can also edit the configuration manually in /etc/argononed.conf
The script will generate several scripts and config files. The main commands are
argonone-configto config the fan behavior
argonone-uninstallto remove all the scripts and services (conf file remains though)
I also added a custom command:
argonone-tempmonwhich monitors the temperature using the Linux
We have been testing this for over a week now and works perfectly
This has been developed in an afternoon and has been only tested on my Raspberry Pi 4. No issues so far, but big disclaimer nonetheless: use at your own risk.
